Offered in PVC, CPVC, and now PVDF materials. PVC and CPVC valves are NSF/ANSI 61-G Listed. O-rings are FPM or EPDM, with reversible PTFE seats. Sizes 1/2” – 2” rated at 250psi / 2-1/2” to 4”rated at 235 PSI at 70°F Non Shock. Ratings may be subject to material and connection type.
Unit of Measure

Size

N/A 3"

Body Material

N/A PVC

Seals

N/A FPM

End Connection

N/A Flanged

Weight

N/A 15.85 lb7.20 kg

Cv Coefficient

N/A 490.0

Flow Configuration

N/A Bi-directional

Series

N/A TB

A

N/A 10.56 in268.22 mm

H

N/A 6.21 in157.73 mm

B

N/A 3.52 in89.41 mm

C

N/A 6.40 in162.56 mm

D1

N/A 5.50 in139.70 mm

D2

N/A 5.50 in139.70 mm

F

N/A 14.62 in371.35 mm
